How do I convert an image to XREF in AutoCAD? (98% Fix)

5/5 - (1030 votes)

Today you will learn about how to convert an image to XREF in AutoCAD, and how to turn a drawing into an XREF ref, and learn about how to convert an AutoCAD drawing to XREF.

Do you know how to convert an image to XREF in AutoCAD?

In this article, you connect an outside reference to your drawing.

An outside reference connects a drawing or picture file. Do you know if it is not the same as a block that embeds, which makes a duplicate?

In the Addition tab, in the Reference Board panel, click Attach.
To reference a picture, in the Document of Type click All picture files.
In the Select Reference dialog box, file, peruse a folder & select a record file.
In the attached Outside Reference discourse box, determine the situation & scale choices.
Place & select the external outside reference to show the logical tab. Utilize the tab to alter the reference. Source: AutoCAD official

How do I convert an AutoCAD drawing to XREF?

1. First of all, click the Insert tab, then the Reference board, then the Attach tool.

2. In the Select Reference Document discourse box, select at least one record file you need to append, & afterward click Open.

3. In the attached Outer Reference exchange box, under Reference Type, choose Attachment.

4. Determine the inclusion point, turn point & scale. Click Determine On-Screen to utilize the pointing gadget or device.

5. The attachment incorporates all settled x refs.

6. At the last stage, Click ok.

Read More: AutoCAD vs Fusion 360 and Is Fusion 360 the same as AutoCAD?

FAQ on How do I convert an image to XREF in AutoCAD

How do you turn a drawing into an x-ref?

Pick the block to switch over completely to an XREF: Select your desired block to change over completely to an outer reference.

In the Save As discourse box that shows up, enter the filename & place where you need to save the outer reference, then, at that point, click Save.

All events of the block in the drawing are changed over.
